Hoop type thermocouple

•

WRNT-04 series Hoop type thermocouple Application of temperature measurement in pipe wall, the clamp…

Productoverview:
WRNT-04 series Hoop type thermocouple Application of temperature measurement in pipe wall, the clamping device clamps or hoop, without welding can be heat plate and pipe temperature probe pressure welding has the advantages of convenient disassembly, sensitive, and reliable measurement of shock compression. Is the common use of natural gas, petroleum chemical industry, power plants and other industries products.
Two, work principle:
WRNT-04 series Hoop type thermocouple The electrode is composed of two different conductor materials. When there is temperature difference between the measuring terminal end with the reference, will produce thermal potential, the instrument will display relevant thermal potential temperature.
Thermocouple The thermoelectric power will increase as the temperature measuring end, thermoelectric sizeonly withthermocouple conductor material and the temperature difference between the two ends of the length, diameter and thermal electrode without thermocouple assembly is mainly composed of a junction box, protection tube, insulation casing, terminals, power extremely basic structure, and with a variety of mounting and fixing device composition.

Three, application:
WRNT-04 series Hoop type thermocouple Is the thermode from removable protective industrial thermocouple tube removed. Use and display instrument and record instrument or computer accessories, can measure the production process in a variety of gas, liquid, and solid surface melt temperature.

Four, main features:
1, simple assembly, convenient replacement;
2, the pressure spring type temperature sensing element, good seismic performance;
3, large measuring range.

Five, technical parameters:
1, electrical outlet: M20 * 1.5, NPT1/2;
2, protection grade: IP65;
3, precision grade: AI.

Sixth, specifications Model：

Seven, Design selection and ordering information:
1, division no.;
2, precision grade;
3, material;
4, the length or depth of insertion.
Customer service service commitment:
1, my company sold Zhongwei Thermocouple series The product within twelve months of quality problems, responsible for free maintenance.
2, the warranty period if the products of our company have any quality problems, our company is responsible for free repair or replacement.
3, the warranty period if the user use undeserved, cause damage to the product, our company is responsible for the maintenance, collect the damaged parts cost.
4, after the warranty period of product quality problems, our company is responsible for the maintenance, collect the damaged parts cost.
5, if the user needs to our service, our company in the province of the user service personnel arrived at the scene within 12 hours, arrived at the scene 48 hours outside users.
